INA KR19-PP-RR-A

Özellikler

Marka	INA
Ürün No	KR19-PP-RR-A INA
Üretici No	0057422850000
EAN	4012802050349
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	8
Dış (D) MM	19
En (B) MM	11
İç (d) Inch	0.315
Dış (D) Inch	0.748
En (B) Inch	0.4331
Ağırlık	0.0285 kg

Ürün Özellikleri

Fok	2L - Her İki Tarafta LS Contası
Excenterring	Other Mounting Method
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	8
Width of the roller stud (B) mm	32
Basic dynamic load rating, radial (C r w)	3550
Temel statik yük derecesi, radyal (C 0r)	4100
Speed on permanent grease lubrication (n D G)	11000
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Stud type track rollers KR..-PP, with axial guidance, plastic axial plain washers on both sides

Suffix description

PP	Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103
RR	Protected Against Corrosion By Corrotect® Special Coating
A	Alteration In Internal Construction. Identical To Old Notation
