INA KBK10X13X14,5-A/0-2

Özellikler

Marka	INA
Ürün No	KBK10X13X14,5-A/0-2 INA
Üretici No	0007329900061
EAN	4054362429807
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	10
Dış (D) MM	13
En (B) MM	14,5
İç (d) Inch	0.3937
Dış (D) Inch	0.5118
En (B) Inch	0.5709
Ağırlık	0.005 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	10
Outside diameter of needle roller complement (E w) mm	13
Width (B c) mm	14,5
Radial Static Load Rating C0r (N)	6600
Radial Dynamic Load Rating Cr (N)	5400
Temel statik yük derecesi, radyal (C 0r)	"6600.0000"
Hız sınırlaması (n G)	29500
ECLASS number	23-05-09-04
ECLASS2 number	23-05-09-04
Medias description	Needle roller cage assembly KBK, single row, similar KBK, piston pin bearing

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-2

Micron - Needle Sort
