INA K15X21X15-A/-2-4

Özellikler

Marka	INA
Ürün No	K15X21X15-A/-2-4 INA
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	21
En (B) MM	15
İç (d) Inch	0.5906
Dış (D) Inch	0.8268
En (B) Inch	0.5906
Ağırlık	0.013 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Outside diameter of needle roller complement (E w) mm	21
Width (B c) mm	15
Radial Static Load Rating C0r (N)	16400
Radial Dynamic Load Rating Cr (N)	14300
Temel statik yük derecesi, radyal (C 0r)	"16400.0000"
Hız sınırlaması (n G)	23600
Referans Hızı (n u03d1r)	14700
ECLASS number	23-05-09-04
ECLASS2 number	23-05-09-04
Medias description	Needle roller cage assembly K, single row

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/-2-4

Micron - Needle Sort
