INA HK1616-AS1-B
Fiyatı: 89.60 ₺
Özellikler
| Marka | INA |
| Ürün No | HK1616-AS1-B INA |
| Üretici No | 0000603990000 |
| EAN | 4012802422634 |
| Kategori | İğne Makaralı ve Kafes Tertibatı |
| İç (d) MM | 16 |
| Dış (D) MM | 22 |
| En (B) MM | 16 |
| İç (d) Inch | 0.6299 |
| Dış (D) Inch | 0.8661 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.0154 kg |
| Fok | Kapaksız |
| Under roller diameter (F w) mm | 16 |
| Width (C) mm | 16 |
| Temel statik yük derecesi, radyal (C 0r) | 15300 |
| Hız sınırlaması (n G) | 15600 |
| Limiting speed for grease lubrication (n G Grease) | 9300 |
| Referans Hızı (n u03d1r) | 11600 |
| ECLASS number | 23-05-09-05 |
| ECLASS2 number | 23-05-09-05 |
| AS1 | Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes |
| B | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
