INAÜrün bilgileri
Ürün fiyatı109,00 ₺
- İç çap (d)
- 16 mm
- Dış çap (D)
- 22 mm
- Genişlik (B)
- 12 mm
- Ağırlık
- 0.012 kg
ÜRÜNÜ YAKINDAN TANIYIN
Teknik özellikler
Özellikler
| Marka | INA |
|---|---|
| Ürün No | HK1612-AS1-B-QX10J INA |
| Kategori | İğne Makaralı ve Kafes Tertibatı |
Ağırlık ve Boyutlar
| İç (d) MM | 16 |
|---|---|
| Dış (D) MM | 22 |
| En (B) MM | 12 |
| İç (d) Inch | 0.6299 |
| Dış (D) Inch | 0.8661 |
| En (B) Inch | 0.4724 |
| Ağırlık | 0.012 kg |
Ürün Özellikleri
| Kapak tipi | Kapaksız |
|---|
Data from Schaeffler (medias)
| ECLASS number | 23-05-09-05 |
|---|---|
| ECLASS2 number | 23-05-09-05 |
Suffix description
| AS1 | Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes |
|---|---|
| B | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| QX10J | Additional Quality Inspection |
