INA HK1516-AS1-B
Fiyatı: 99.40 ₺
Özellikler
| Marka | INA |
| Ürün No | HK1516-AS1-B INA |
| Üretici No | 0000603640000 |
| EAN | 4012802443639 |
| Kategori | İğne Makaralı ve Kafes Tertibatı |
| İç (d) MM | 15 |
| Dış (D) MM | 21 |
| En (B) MM | 16 |
| İç (d) Inch | 0.5906 |
| Dış (D) Inch | 0.8268 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.0146 kg |
| Fok | Kapaksız |
| Under roller diameter (F w) mm | 15 |
| Width (C) mm | 16 |
| Radial Static Load Rating C0r (N) | 14400 |
| Radial Dynamic Load Rating Cr (N) | 10500 |
| Temel statik yük derecesi, radyal (C 0r) | "14400.0000" |
| Hız sınırlaması (n G) | 16500 |
| Limiting speed for grease lubrication (n G Grease) | 9900 |
| Referans Hızı (n u03d1r) | 12300 |
| ECLASS number | 23-05-09-05 |
| ECLASS2 number | 23-05-09-05 |
| Medias description | Drawn cup needle roller bearing open end HK..-AS1-B, single row, with cage |
| AS1 | Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes |
| B | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
