INA HFLZ101416-L564

Özellikler

Marka	INA
Ürün No	HFLZ101416-L564 INA
Üretici No	0016002650962
Alternatif Kodu	HFLZ101416
EAN	4047643183147
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	15,875
Dış (D) MM	22,225
En (B) MM	25,4
İç (d) Inch	0.625
Dış (D) Inch	0.875
En (B) Inch	1
Ağırlık	0.023 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	15,875
Radial Static Load Rating C0r (N)	8500
Radial Dynamic Load Rating Cr (N)	7400
Temel statik yük derecesi, radyal (C 0r)	"8500.0000"
Limiting speed for rotating shaft (n GW)	8500
Limiting speed for rotating outer ring (n GA)	5000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFLZ, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
