INA HFL3530-L564

Özellikler

Marka	INA
Ürün No	HFL3530-L564 INA
Üretici No	0016002570962
Alternatif Kodu	HFL3530
EAN	4012802042702
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	42
En (B) MM	30
İç (d) Inch	1.378
Dış (D) Inch	1.6535
En (B) Inch	1.1811
Ağırlık	0.058 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	35
Radial Static Load Rating C0r (N)	18800
Radial Dynamic Load Rating Cr (N)	12200
Temel statik yük derecesi, radyal (C 0r)	"18800.0000"
Limiting speed for rotating shaft (n GW)	3900
Limiting speed for rotating outer ring (n GA)	3900
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
