INA HFL3030-L564
Fiyatı: 862.80 ₺
Özellikler
| Marka | INA |
| Ürün No | HFL3030-L564 INA |
| Üretici No | 0016002490962 |
| Alternatif Kodu |
HFL3030 |
| EAN | 4012802106732 |
| Kategori | İğne Makaralı ve Kafes Tertibatı |
| İç (d) MM | 30 |
| Dış (D) MM | 37 |
| En (B) MM | 30 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 1.4567 |
| En (B) Inch | 1.1811 |
| Ağırlık | 0.055 kg |
| Fok | Kapaksız |
| Under roller diameter (F w) mm | 30 |
| Radial Static Load Rating C0r (N) | 16900 |
| Radial Dynamic Load Rating Cr (N) | 11600 |
| Temel statik yük derecesi, radyal (C 0r) | "16900.0000" |
| Limiting speed for rotating shaft (n GW) | 4500 |
| Limiting speed for rotating outer ring (n GA) | 4500 |
| ECLASS number | 23-05-21-90 |
| ECLASS2 number | 23-05-21-90 |
| Medias description | Drawn cup roller clutch HFL, with bearing |
| L564 | Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
