INA HFL2026-L564

Özellikler

Marka	INA
Ürün No	HFL2026-L564 INA
Üretici No	0016002220962
Alternatif Kodu	HFL2026
EAN	4047643183185
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	26
En (B) MM	26
İç (d) Inch	0.7874
Dış (D) Inch	1.0236
En (B) Inch	1.0236
Ağırlık	0.03 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	20
Radial Static Load Rating C0r (N)	11400
Radial Dynamic Load Rating Cr (N)	8500
Temel statik yük derecesi, radyal (C 0r)	"11400.0000"
Limiting speed for rotating shaft (n GW)	7000
Limiting speed for rotating outer ring (n GA)	6500
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
