INA HFL1826-L564

Özellikler

Marka	INA
Ürün No	HFL1826-L564 INA
Üretici No	0016002140962
Alternatif Kodu	HFL1826
EAN	4047643006354
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	18
Dış (D) MM	24
En (B) MM	26
İç (d) Inch	0.7087
Dış (D) Inch	0.9449
En (B) Inch	1.0236
Ağırlık	0.025 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	18
Radial Static Load Rating C0r (N)	10200
Radial Dynamic Load Rating Cr (N)	8000
Temel statik yük derecesi, radyal (C 0r)	"10200.0000"
Limiting speed for rotating shaft (n GW)	7500
Limiting speed for rotating outer ring (n GA)	7500
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
