INA HFL1022-L564

Özellikler

Marka	INA
Ürün No	HFL1022-L564 INA
Üretici No	0016001680962
Alternatif Kodu	HFL1022
EAN	4012802369588
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	10
Dış (D) MM	14
En (B) MM	22
İç (d) Inch	0.3937
Dış (D) Inch	0.5512
En (B) Inch	0.8661
Ağırlık	0.008 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	10
Radial Static Load Rating C0r (N)	4500
Radial Dynamic Load Rating Cr (N)	3950
Temel statik yük derecesi, radyal (C 0r)	"4500.0000"
Limiting speed for rotating shaft (n GW)	14000
Limiting speed for rotating outer ring (n GA)	11000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
