INA HF0812-L564

Özellikler

Marka	INA
Ürün No	HF0812-L564 INA
Üretici No	0013657030962
Alternatif Kodu	HF0812
EAN	4012802611892
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	8
Dış (D) MM	12
En (B) MM	12
İç (d) Inch	0.315
Dış (D) Inch	0.4724
En (B) Inch	0.4724
Ağırlık	0.0035 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	8
Permissible torque (M d per)	3.15
Limiting speed for rotating shaft (n GW)	17000
Limiting speed for rotating outer ring (n GA)	12000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutches HF, with steel springs

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
