INA HF0612-L564-QX10J

Özellikler

Marka	INA
Ürün No	HF0612-L564-QX10J INA
Üretici No	0013721737003
Alternatif Kodu	HF0612
EAN	4054362381181
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	6
Dış (D) MM	10
En (B) MM	12
İç (d) Inch	0.2362
Dış (D) Inch	0.3937
En (B) Inch	0.4724
Ağırlık	0.003 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	6
Permissible torque (M d per)	1.76
Limiting speed for rotating shaft (n GW)	23000
Limiting speed for rotating outer ring (n GA)	13000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
QX10J	Additional Quality Inspection
