INA GNE30-XL-KRR-B
Fiyatı: 1,267.20 ₺
Özellikler
| Marka | INA |
| Ürün No | GNE30-XL-KRR-B INA |
| Üretici No | 0009441730000 |
| Alternatif Kodu |
GNE30-KRR-B |
| EAN | 4012802803686 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 30 |
| Dış (D) MM | 72 |
| En (B) MM | 50,2 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 2.8346 |
| En (B) Inch | 1.9764 |
| Ağırlık | 0.54 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | No Special Treatment |
| Outside diameter (D SP) mm | 72 |
| Genişlik (b) mm | 36,6 |
| Locking collar total width (B 1) mm | 50,2 |
| Radial Static Load Rating C0r (N) | 16700 |
| Radial Dynamic Load Rating Cr (N) | 31500 |
| Temel statik yük derecesi, radyal (C 0r) | "16700.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides |
| XL | X-Life |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
