INA GNE100-KRR-B-FA107
Fiyatı: 16,397.80 ₺
Özellikler
| Marka | INA |
| Ürün No | GNE100-KRR-B-FA107 INA |
| Üretici No | 0004880890000 |
| EAN | 4012802784879 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 100 |
| Dış (D) MM | 215 |
| En (B) MM | 109,4 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 8.4646 |
| En (B) Inch | 4.3071 |
| Ağırlık | 12.3 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | I - Lubr Holes on Locating Side |
| Outside diameter (D SP) mm | 215 |
| Genişlik (b) mm | 86 |
| Locking collar total width (B 1) mm | 109,4 |
| Radial Static Load Rating C0r (N) | 141000 |
| Radial Dynamic Load Rating Cr (N) | 184000 |
| Temel statik yük derecesi, radyal (C 0r) | "131000.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing GNE..-KRR-B |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| FA107 | Bearing With Lubrication Holes On The Locating Side |
