INA GIR8-UK

Özellikler

Marka	INA
Ürün No	GIR8-UK INA
Üretici No	0066357090000
Alternatif Kodu	SI8C
EAN	4012802527094
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	8
Dış (D) MM	25
En (B) MM	8
İç (d) Inch	0.315
Dış (D) Inch	0.9843
En (B) Inch	0.315
Ağırlık	0.039 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	16
Radial Static Load Rating C0r (N)	16000
Width inner ring (B) mm	8
Radial Dynamic Load Rating Cr (N)	5850
Temel statik yük derecesi, radyal (C 0r)	"16000.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type F, inner ring curved surface with hard chromium coating, open design, left hand thread

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
