INA GIL20-UK

Özellikler

Marka	INA
Ürün No	GIL20-UK INA
Üretici No	0066352290000
Alternatif Kodu	SIL20C
EAN	4012802526448
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	54
En (B) MM	16
İç (d) Inch	0.7874
Dış (D) Inch	2.126
En (B) Inch	0.6299
Ağırlık	0.32 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	35
Radial Static Load Rating C0r (N)	75600
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	31300
Temel statik yük derecesi, radyal (C 0r)	"75600.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type F, inner ring curved surface with hard chromium coating, open design, left hand thread

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
