INA GIKPSR12-PS
Fiyatı: 2,648.60 ₺
Özellikler
| Marka | INA |
| Ürün No | GIKPSR12-PS INA |
| Üretici No | 0624670340000 |
| EAN | 4012802648133 |
| Kategori | Çubuk Ucu |
| İç (d) MM | 12 |
| Dış (D) MM | 66,5 |
| En (B) MM | 16 |
| İç (d) Inch | 0.4724 |
| Dış (D) Inch | 2.6181 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.107 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 26 |
| Radial Static Load Rating C0r (N) | 9100 |
| Width inner ring (B) mm | 16 |
| Radial Dynamic Load Rating Cr (N) | 24000 |
| Temel statik yük derecesi, radyal (C 0r) | "9100.0000" |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Corrosion-resistant rod end, with internal thread, right hand thread : maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open designfine pith thread connector for standard pneumatic cylinders to DIN ISO 15552 |
| PS | Special Steel, Maintenance Free |
