INA GIKPR16-PW
Fiyatı: 1,210.60 ₺
Özellikler
| Marka | INA |
| Ürün No | GIKPR16-PW INA |
| Üretici No | 0066309600000 |
| Alternatif Kodu |
SIKB16FVZ019 |
| EAN | 4012802523492 |
| Kategori | Çubuk Ucu |
| İç (d) MM | 16 |
| Dış (D) MM | 42 |
| En (B) MM | 21 |
| İç (d) Inch | 0.6299 |
| Dış (D) Inch | 1.6535 |
| En (B) Inch | 0.8268 |
| Ağırlık | 0.2264 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 32 |
| Radial Static Load Rating C0r (N) | 45300 |
| Width inner ring (B) mm | 21 |
| Radial Dynamic Load Rating Cr (N) | 38600 |
| Temel statik yük derecesi, radyal (C 0r) | "45300.0000" |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end with internal thread, right hand thread, maintenance-free, sliding layer: PTFE film, brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design, with fine pitch thread connector for standard pneumatic cylinders to DIN ISO 15552 |
| PW | Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
