INA GIKL20-PW
Fiyatı: 1,592.00 ₺
Özellikler
| Marka | INA |
| Ürün No | GIKL20-PW INA |
| Üretici No | 0066348850000 |
| EAN | 4012802525892 |
| Kategori | Çubuk Ucu |
| İç (d) MM | 20 |
| Dış (D) MM | 50 |
| En (B) MM | 25 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 1.9685 |
| En (B) Inch | 0.9843 |
| Ağırlık | 0.38 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 40 |
| Radial Static Load Rating C0r (N) | 45600 |
| Width inner ring (B) mm | 25 |
| Radial Dynamic Load Rating Cr (N) | 56600 |
| Temel statik yük derecesi, radyal (C 0r) | "45600.0000" |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end with internal thread, left hand thread maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design |
| PW | Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
