INA GIKL10-PW-A

Çubuk Ucu
Kategorideki ürünler →
INA GIKL10-PW-A
INAÜrün bilgileri
Ürün fiyatı627,80 ₺
İç çap (d)
10 mm
Dış çap (D)
29 mm
Genişlik (B)
14 mm
Ağırlık
0.072 kg

Bu ürün hakkında bilgi alın.

WhatsApp’tan sorunTelefon: 0(850) 840 8255
ÜRÜNÜ YAKINDAN TANIYIN

Teknik özellikler

Özellikler

Marka INA
Ürün No GIKL10-PW-A INA
Üretici No 0066348420000
EAN 4012802525786
Kategori Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM 10
Dış (D) MM 29
En (B) MM 14
İç (d) Inch 0.3937
Dış (D) Inch 1.1417
En (B) Inch 0.5512
Ağırlık 0.072 kg

Ürün Özellikleri

Kapak tipi Kapaksız
Contact Material Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm 22
Radial Static Load Rating C0r (N) 18500
Width inner ring (B) mm 14
Radial Dynamic Load Rating Cr (N) 18100
Temel statik yük derecesi, radyal (C 0r) "18500.0000"
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with internal thread, left hand thread maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

PW Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
