INA GE80-SW-A
Fiyatı: 5,984.40 ₺
Özellikler
| Marka | INA |
| Ürün No | GE80-SW-A INA |
| Üretici No | 0066519840000 |
| Alternatif Kodu |
GAC80F |
| EAN | 4012802532753 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 80 |
| Dış (D) MM | 125 |
| En (B) MM | 29 |
| İç (d) Inch | 3.1496 |
| Dış (D) Inch | 4.9213 |
| En (B) Inch | 1.1417 |
| Ağırlık | 1.437 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 125 |
| Height (T) mm | 29 |
| Radial Static Load Rating C0r (N) | 1220000 |
| Width inner ring (B) mm | 27 |
| Radial Dynamic Load Rating Cr (N) | 734000 |
| Temel statik yük derecesi, radyal (C 0r) | "1220000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
| SW | Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A | Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
