INA GE70-DO-C2
Fiyatı: 2,086.40 ₺
Özellikler
| Marka | INA |
| Ürün No | GE70-DO-C2 INA |
| Üretici No | 0066482310020 |
| Alternatif Kodu |
GE70ES |
| EAN | 4012802530735 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 70 |
| Dış (D) MM | 105 |
| En (B) MM | 49 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 4.1339 |
| En (B) Inch | 1.9291 |
| Ağırlık | 1.55 kg |
| Fok | Kapaksız |
| Contact Material | Steel on Steel |
| Outside diameter bearing (D) mm | 105 |
| Radial Static Load Rating C0r (N) | 1560000 |
| Width inner ring (B) mm | 49 |
| Radial Dynamic Load Rating Cr (N) | 313000 |
| Temel statik yük derecesi, radyal (C 0r) | "1560000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, open design |
| DO | Sliding Contact Surface Steel/Steel |
| C2 | Bearing Internal Clearance Smaller Than Normal. (For Spherical Plain Bearings Requiring Maintenance) |
