INA GE30-XL-KRR-B-FA101
Fiyatı: 3,498.00 ₺
Özellikler
| Marka | INA |
| Ürün No | GE30-XL-KRR-B-FA101 INA |
| Üretici No | 0008406100000 |
| Alternatif Kodu |
GE30-KRR-B-FA101 |
| EAN | 4012802788587 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 30 |
| Dış (D) MM | 62 |
| En (B) MM | 48,5 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 2.4409 |
| En (B) Inch | 1.9094 |
| Ağırlık | 0.38 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | G - High/Low Tem Design -40/+180°C |
| Outside diameter (D SP) mm | 62 |
| Genişlik (b) mm | 36,5 |
| Locking collar total width (B 1) mm | 48,5 |
| Radial Static Load Rating C0r (N) | 11300 |
| Radial Dynamic Load Rating Cr (N) | 20700 |
| Temel statik yük derecesi, radyal (C 0r) | "11300.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing GE..-XL-KRR-B-FA101 |
| XL | X-Life |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| FA101 | High And Low Temperature Design -40 ~ 180u2103 |
