INA GE17-UK-2RS-A

Özellikler

Marka	INA
Ürün No	GE17-UK-2RS-A INA
Üretici No	0066499550000
Alternatif Kodu	GE17TXE-2RS
EAN	4012802531480
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	17
Dış (D) MM	30
En (B) MM	14
İç (d) Inch	0.6693
Dış (D) Inch	1.1811
En (B) Inch	0.5512
Ağırlık	0.0407 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	30
Radial Static Load Rating C0r (N)	81300
Width inner ring (B) mm	14
Radial Dynamic Load Rating Cr (N)	48800
Temel statik yük derecesi, radyal (C 0r)	"81300.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, sealed

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
2RS	Lip Seals On Both Sides
A	Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
