INA GE120-AW-A
Fiyatı: 36,908.00 ₺
Özellikler
| Marka | INA |
| Ürün No | GE120-AW-A INA |
| Üretici No | 0066521070000 |
| Alternatif Kodu |
GX120F |
| EAN | 4012802532845 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 120 |
| Dış (D) MM | 230 |
| En (B) MM | 64 |
| İç (d) Inch | 4.7244 |
| Dış (D) Inch | 9.0551 |
| En (B) Inch | 2.5197 |
| Ağırlık | 13.31 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 230 |
| Height (T) mm | 64 |
| Width inner ring (B) mm | 52 |
| Axial Static Load Rating C0a (N) | 6230000 |
| Axial Dynamic Load Rating Ca (N) | 3740000 |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design |
| AW | Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
