INA GE100-XL-KRR-B
Fiyatı: 8,733.80 ₺
Özellikler
| Marka | INA |
| Ürün No | GE100-XL-KRR-B INA |
| Üretici No | 0008777430000 |
| Alternatif Kodu |
GE100-KRR-B |
| EAN | 4012802794960 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 100 |
| Dış (D) MM | 180 |
| En (B) MM | 75 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 2.9528 |
| Ağırlık | 4.65 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | No Special Treatment |
| Outside diameter (D SP) mm | 180 |
| Genişlik (b) mm | 57,5 |
| Locking collar total width (B 1) mm | 75 |
| Radial Static Load Rating C0r (N) | 93000 |
| Radial Dynamic Load Rating Cr (N) | 130000 |
| Temel statik yük derecesi, radyal (C 0r) | "93000.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing GE..-XL-KRR-B |
| XL | X-Life |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
