INA GE10-FW

Özellikler

Marka	INA
Ürün No	GE10-FW INA
Üretici No	0066497180000
Alternatif Kodu	GEH10C
EAN	4012802531176
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	10
Dış (D) MM	22
En (B) MM	12
İç (d) Inch	0.3937
Dış (D) Inch	0.8661
En (B) Inch	0.4724
Ağırlık	0.0197 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	22
Radial Static Load Rating C0r (N)	28400
Width inner ring (B) mm	12
Radial Dynamic Load Rating Cr (N)	11300
Temel statik yük derecesi, radyal (C 0r)	"28400.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating DIN ISO 12240-1, dimension series G, open design

Suffix description

FW	Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring
