ÜRÜN KATALOĞU

INA GAR45-UK-2RS-A

Çubuk Ucu
Kategorideki ürünler →
INA GAR45-UK-2RS-A
INAÜrün bilgileri
Ürün fiyatı4.868,80 ₺
İç çap (d)
45 mm
Dış çap (D)
102 mm
Genişlik (B)
35 mm
Ağırlık
2.55 kg

Bu ürün hakkında bilgi alın.

WhatsApp’tan sorunTelefon: 0(850) 840 8255
ÜRÜNÜ YAKINDAN TANIYIN

Teknik özellikler

Özellikler

Marka INA
Ürün No GAR45-UK-2RS-A INA
Üretici No 0066466620000
Alternatif Kodu SAA45TXE-2RS <br />
EAN 4012802529197
Kategori Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM 45
Dış (D) MM 102
En (B) MM 35
İç (d) Inch 1.7717
Dış (D) Inch 4.0157
En (B) Inch 1.378
Ağırlık 2.55 kg

Ürün Özellikleri

Kapak tipi 2RS - İki Tarafta Kauçuk Conta
Contact Material Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm 68
Outer eye diameter (d 2) mm 102
Radial Static Load Rating C0r (N) 259000
Width inner ring (B) mm 32
Radial Dynamic Load Rating Cr (N) 360000
Temel statik yük derecesi, radyal (C 0r) &quot;259000.0000&quot;
Total length external thread rod (l 2) mm 214
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, right hand thread, maintenance-free, sliding layer: ELGOGLIDE DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, sealed

Suffix description

UK Sliding Contact Surface Hard Chromium/PTFE Composite
2RS Lip Seals On Both Sides
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
