INA GAR17-UK-2RS-A

Çubuk Ucu
Kategorideki ürünler →
INA GAR17-UK-2RS-A
INAÜrün bilgileri
Ürün fiyatı1.050,60 ₺
İç çap (d)
17 mm
Dış çap (D)
46 mm
Genişlik (B)
14 mm
Ağırlık
0.18 kg

Bu ürün hakkında bilgi alın.

WhatsApp’tan sorunTelefon: 0(850) 840 8255
ÜRÜNÜ YAKINDAN TANIYIN

Teknik özellikler

Özellikler

Marka INA
Ürün No GAR17-UK-2RS-A INA
Üretici No 0066467940000
Alternatif Kodu SA17C-2RS <br />
EAN 4012802529234
Kategori Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM 17
Dış (D) MM 46
En (B) MM 14
İç (d) Inch 0.6693
Dış (D) Inch 1.811
En (B) Inch 0.5512
Ağırlık 0.18 kg

Ürün Özellikleri

Kapak tipi 2RS - İki Tarafta Kauçuk Conta
Contact Material Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm 30
Outer eye diameter (d 2) mm 46
Radial Static Load Rating C0r (N) 56500
Width inner ring (B) mm 14
Radial Dynamic Load Rating Cr (N) 48800
Temel statik yük derecesi, radyal (C 0r) &quot;56500.0000&quot;
Total length external thread rod (l 2) mm 92
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, right hand thread, maintenance-free, sliding layer: ELGOGLIDE DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, sealed

Suffix description

UK Sliding Contact Surface Hard Chromium/PTFE Composite
2RS Lip Seals On Both Sides
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
