| Outside diameter bearing (D) mm |
26 |
| Outer eye diameter (d 2) mm |
40 |
| Radial Static Load Rating C0r (N) |
41600 |
| Width inner ring (B) mm |
12 |
| Radial Dynamic Load Rating Cr (N) |
17800 |
| Temel statik yük derecesi, radyal (C 0r) |
"41600.0000" |
| Total length external thread rod (l 2) mm |
83 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
