INA GAKR5-PB-A

INA GAKR5-PB-A
INA GAKR5-PB-A rulman resim 1
INA GAKR5-PB-A rulman resim 2
INA GAKR5-PB-A rulman resim 3
INA GAKR5-PB-A rulman resim 4
Fiyatı: 625.80 ₺
Özellikler
Marka INA
Ürün No GAKR5-PB-A INA
Üretici No 0066336170000
EAN 4012802524451
Kategori Çubuk Ucu
Ağırlık ve Boyutlar
İç (d) MM 5
Dış (D) MM 18
En (B) MM 8
İç (d) Inch 0.1969
Dış (D) Inch 0.7087
En (B) Inch 0.315
Ağırlık 0.015 kg
Ürün Özellikleri
Fok Kapaksız
Contact Material Steel on Bronze
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 13
Radial Static Load Rating C0r (N) 4900
Width inner ring (B) mm 8
Radial Dynamic Load Rating Cr (N) 3330
Temel statik yük derecesi, radyal (C 0r) "4900.0000"
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, right hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design
Suffix description
PB Sliding Contact Surface Is Steel/Bronze
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
