INA GAKL8-PW-A
Fiyatı: 500.40 ₺
Özellikler
| Marka | INA |
| Ürün No | GAKL8-PW-A INA |
| Üretici No | 0066334550000 |
| Alternatif Kodu |
SALKB8F |
| EAN | 4012802524215 |
| Kategori | Çubuk Ucu |
| İç (d) MM | 8 |
| Dış (D) MM | 24 |
| En (B) MM | 12 |
| İç (d) Inch | 0.315 |
| Dış (D) Inch | 0.9449 |
| En (B) Inch | 0.4724 |
| Ağırlık | 0.032 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 19 |
| Outer eye diameter (d 2) mm | 24 |
| Radial Static Load Rating C0r (N) | 12900 |
| Width inner ring (B) mm | 12 |
| Radial Dynamic Load Rating Cr (N) | 12900 |
| Temel statik yük derecesi, radyal (C 0r) | "12900.0000" |
| Total length external thread rod (l 2) mm | 54 |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end GAKL..-PW, external threads, maintenance-free |
| PW | Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
| A | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
