INA GAKL30-PW

Özellikler

Marka	INA
Ürün No	GAKL30-PW INA
Üretici No	0066309520000
EAN	4012802523485
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	70
En (B) MM	37
İç (d) Inch	1.1811
Dış (D) Inch	2.7559
En (B) Inch	1.4567
Ağırlık	1.1 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	55
Outer eye diameter (d 2) mm	70
Radial Static Load Rating C0r (N)	95900
Width inner ring (B) mm	37
Radial Dynamic Load Rating Cr (N)	114000
Temel statik yük derecesi, radyal (C 0r)	"95900.0000"
Total length external thread rod (l 2) mm	145
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end GAKL..-PW, external threads, maintenance-free

Suffix description

PW	Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
