INA GAKL25-PW
Fiyatı: 1,999.80 ₺
Özellikler
| Marka | INA |
| Ürün No | GAKL25-PW INA |
| Üretici No | 0066388210000 |
| EAN | 4012802527735 |
| Kategori | Çubuk Ucu |
| İç (d) MM | 25 |
| Dış (D) MM | 60 |
| En (B) MM | 31 |
| İç (d) Inch | 0.9843 |
| Dış (D) Inch | 2.3622 |
| En (B) Inch | 1.2205 |
| Ağırlık | 0.64 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 47 |
| Outer eye diameter (d 2) mm | 60 |
| Radial Static Load Rating C0r (N) | 72900 |
| Width inner ring (B) mm | 31 |
| Radial Dynamic Load Rating Cr (N) | 84800 |
| Temel statik yük derecesi, radyal (C 0r) | "72900.0000" |
| Total length external thread rod (l 2) mm | 124 |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end GAKL..-PW, external threads, maintenance-free |
| PW | Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
