INA G1108-KRR-B-AS2/V
Fiyatı: 995.40 ₺
Özellikler
| Marka | INA |
| Ürün No | G1108-KRR-B-AS2/V INA |
| Üretici No | 0502720390000 |
| Alternatif Kodu |
YEL208-108-2F |
| EAN | 4054362366645 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 38,1 |
| Dış (D) MM | 80 |
| En (B) MM | 56,3 |
| İç (d) Inch | 1.5 |
| Dış (D) Inch | 3.1496 |
| En (B) Inch | 2.2165 |
| Ağırlık | 0.72 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | No Special Treatment |
| Outside diameter (D SP) mm | 80 |
| Genişlik (b) mm | 42,9 |
| Locking collar total width (B 1) mm | 56,5 |
| Radial Static Load Rating C0r (N) | 19800 |
| Radial Dynamic Load Rating Cr (N) | 34500 |
| Temel statik yük derecesi, radyal (C 0r) | "19800.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing G1..-KRR-B-AS2/V |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| AS2/V | Bearing Outer Ring With Two Lubrication Holes In Offset Planes |
