INA E50-XL-KLL-ID+21+10
Fiyatı: 1,585.80 ₺
Özellikler
| Marka | INA |
| Ürün No | E50-XL-KLL-ID+21+10 INA |
| Üretici No | 0008523920939 |
| Alternatif Kodu |
E50-KLL-ID+21+10 |
| EAN | 4012802799835 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 50 |
| Dış (D) MM | 90 |
| En (B) MM | 62,8 |
| İç (d) Inch | 1.9685 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 2.4724 |
| Ağırlık | 1 kg |
| Fok | 2L - Her İki Tarafta LS Contası |
| Yağlama | Standart Yağlama |
| Özel Muamele | No Special Treatment |
| Genişlik (b) mm | 49,2 |
| Locking collar total width (B 1) mm | 62,8 |
| Radial Static Load Rating C0r (N) | 23200 |
| Radial Dynamic Load Rating Cr (N) | 37500 |
| Temel statik yük derecesi, radyal (C 0r) | "23200.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearings E..-KLL, cylindrical outer ring, location by eccentric locking collar, L seals on both sides |
| XL | X-Life |
| K | Conrad (Non-Filling Slot) Type |
| LL | Labyrinth Seals On Both Sides (L Type Seal - All Parts Of The L Type Seal Are Zinc Plated On All Sides In Order To Improve Corrosion Protection - No Seal Friction) |
| B | Bearing With Spherical Outer Ring |
| ID+21+10 | Inner Ring Tolerance In Micron |
