INA E30-XL-KRR

INA E30-XL-KRR
INA E30-XL-KRR rulman resim 1
INA E30-XL-KRR rulman resim 2
INA E30-XL-KRR rulman resim 3
INA E30-XL-KRR rulman resim 4
Fiyatı: 676.60 ₺
Özellikler
Marka INA
Ürün No E30-XL-KRR INA
Üretici No 0008049750000
Alternatif Kodu E30-KRR
EAN 4012802783667
Kategori Muhafazalar İçin Rulmanlar
Ağırlık ve Boyutlar
İç (d) MM 30
Dış (D) MM 62
En (B) MM 48,5
İç (d) Inch 1.1811
Dış (D) Inch 2.4409
En (B) Inch 1.9094
Ağırlık 0.38 kg
Ürün Özellikleri
Fok 2RS - İki Tarafta Kauçuk Conta
Yağlama Standart Yağlama
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 36,5
Locking collar total width (B 1) mm 48,5
Radial Static Load Rating C0r (N) 11300
Radial Dynamic Load Rating Cr (N) 20700
Temel statik yük derecesi, radyal (C 0r) "11300.0000"
ECLASS number 23-05-08-02
ECLASS2 number 23-05-08-02
Medias description Radial insert ball bearings E..-KRR, cylindrical outer ring, location by eccentric locking collar, R seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
