INA BK2020-A

Fiyatı: 148.20 ₺
Özellikler
Marka INA
Ürün No BK2020-A INA
Üretici No 0001770670000
EAN 4012802424898
Kategori İğne Makaralı ve Kafes Tertibatı
Ağırlık ve Boyutlar
İç (d) MM 20
Dış (D) MM 26
En (B) MM 20
İç (d) Inch 0.7874
Dış (D) Inch 1.0236
En (B) Inch 0.7874
Ağırlık 0.027 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Under roller diameter (F w) mm 20
Radial Static Load Rating C0r (N) 26000
Radial Dynamic Load Rating Cr (N) 15700
Hız sınırlaması (n G) 12700
Limiting speed for grease lubrication (n G Grease) 7600
Referans Hızı (n u03d1r) 9300
ECLASS number 23-05-09-06
ECLASS2 number 23-05-09-06
Medias description Drawn cup needle roller bearings with closed end BK, to DIN 618/ISO 3245
Suffix description
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
