INA AXK85110-A/0-10

Fiyatı: 446.60 ₺
Özellikler
Marka INA
Ürün No AXK85110-A/0-10 INA
Üretici No 0000357429065
EAN 4047643173216
Kategori İtme Yatağı - İğne Makaralı
Ağırlık ve Boyutlar
İç (d) MM 85
Dış (D) MM 110
En (B) MM 4
İç (d) Inch 3.3465
Dış (D) Inch 4.3307
En (B) Inch 0.1575
Ağırlık 0.053 kg
Data from Schaeffler (medias)
Outside diameter (D c) mm 110
Rolling element diameter (D W) mm 4
Axial Static Load Rating C0a (N) 290000
Axial Dynamic Load Rating Ca (N) 58000
Hız sınırlaması (n G) 2950
Raceway dimension (E a) mm 108
Raceway dimension (E b) mm 89
Referans Hızı (n u03d1r) 1220
ECLASS number 23-05-11-90
ECLASS2 number 23-05-11-90
Medias description Axial needle roller and cage assemblies, single direction, to DIN 5405-2
Suffix description
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
/0-10 Micron - Needle Sort
