INA AXK6085-A/0-10

INA AXK6085-A/0-10
INA AXK6085-A/0-10 rulman resim 1
INA AXK6085-A/0-10 rulman resim 2
INA AXK6085-A/0-10 rulman resim 3
INA AXK6085-A/0-10 rulman resim 4
INA AXK6085-A/0-10 rulman resim 5
Fiyatı: 142.40 ₺
Özellikler
Marka INA
Ürün No AXK6085-A/0-10 INA
Üretici No 0000356299065
EAN 4012802369014
Kategori İtme Yatağı - İğne Makaralı
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 85
En (B) MM 3
İç (d) Inch 2.3622
Dış (D) Inch 3.3465
En (B) Inch 0.1181
Ağırlık 0.0361 kg
Data from Schaeffler (medias)
Outside diameter (D c) mm 85
Rolling element diameter (D W) mm 3
Axial Static Load Rating C0a (N) 234000
Axial Dynamic Load Rating Ca (N) 45000
Hız sınırlaması (n G) 3950
Raceway dimension (E a) mm 83
Raceway dimension (E b) mm 65
Referans Hızı (n u03d1r) 1590
ECLASS number 23-05-11-90
ECLASS2 number 23-05-11-90
Medias description Axial needle roller and cage assemblies, single direction, to DIN 5405-2
Suffix description
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
/0-10 Micron - Needle Sort
