INA AXK3552-A/0-10

Özellikler

Marka	INA
Ürün No	AXK3552-A/0-10 INA
Üretici No	0000355219065
EAN	4047643173148
Kategori	İtme Yatağı - İğne Makaralı

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	52
En (B) MM	2
İç (d) Inch	1.378
Dış (D) Inch	2.0472
En (B) Inch	0.0787
Ağırlık	0.0093 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	52
Rolling element diameter (D W) mm	2
Axial Static Load Rating C0a (N)	81000
Axial Dynamic Load Rating Ca (N)	17900
Hız sınırlaması (n G)	6600
Raceway dimension (E a) mm	51
Raceway dimension (E b) mm	39
Referans Hızı (n u03d1r)	2800
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/0-10

Micron - Needle Sort
