INA AXK160200-A/0-10
Fiyatı: 2,165.80 ₺
Özellikler
| Marka | INA |
| Ürün No | AXK160200-A/0-10 INA |
| Üretici No | 0000359639065 |
| EAN | 4012802369489 |
| Kategori | İtme Yatağı - İğne Makaralı |
| İç (d) MM | 160 |
| Dış (D) MM | 200 |
| En (B) MM | 5 |
| İç (d) Inch | 6.2992 |
| Dış (D) Inch | 7.874 |
| En (B) Inch | 0.1969 |
| Ağırlık | 0.25 kg |
| Outside diameter (D c) mm | 200 |
| Rolling element diameter (D W) mm | 5 |
| Axial Static Load Rating C0a (N) | 1020000 |
| Axial Dynamic Load Rating Ca (N) | 148000 |
| Hız sınırlaması (n G) | 1600 |
| Raceway dimension (E a) mm | 197 |
| Raceway dimension (E b) mm | 166 |
| Referans Hızı (n u03d1r) | 620 |
| ECLASS number | 23-05-11-90 |
| ECLASS2 number | 23-05-11-90 |
| Medias description | Axial needle roller and cage assemblies, single direction, to DIN 5405-2 |
| A | The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| /0-10 | Micron - Needle Sort |
