FAG HCB71920-E-T-P4S-K5-UL

Özellikler

Marka	FAG
Ürün No	HCB71920-E-T-P4S-K5-UL FAG
Üretici No	0385015700000
EAN	4026677055392
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	100
Dış (D) MM	140
En (B) MM	20
İç (d) Inch	3.937
Dış (D) Inch	5.5118
En (B) Inch	0.7874
Ağırlık	0.66 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	K5 - P4S + K5
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	20
Temel statik yük derecesi, radyal (C 0r)	40500
Limiting speed for grease lubrication (n G Grease)	12000
Limiting speed for oil lubrication (n G Oil)	18000

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL	Single Bearing, Universal, Light Preload
