FAG HCB7016-EDLR-T-P4S-UL

Özellikler

Marka	FAG
Ürün No	HCB7016-EDLR-T-P4S-UL FAG
Üretici No	0386230560000
EAN	4026677738493
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	80
Dış (D) MM	125
En (B) MM	22
İç (d) Inch	3.1496
Dış (D) Inch	4.9213
En (B) Inch	0.8661
Ağırlık	0.71 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	DLR

Data from Schaeffler (medias)

Genişlik (b) mm	22
Radial Static Load Rating C0r (N)	37500
Radial Dynamic Load Rating Cr (N)	61000
Temel statik yük derecesi, radyal (C 0r)	"37500.0000"
Limiting speed for grease lubrication (n G Grease)	14000
Limiting speed for oil lubrication (n G Oil)	22000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Spindle bearings HCB70..-EDLR, adjusted, matched pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances, for direct oil feed via outer ring, with inserted O rings

Suffix description

E	25° Contact Angle
DLR	Direct Lube, Integral O-Ring
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL	Single Bearing, Universal, Light Preload
