FAG HCB7004-C-T-P4S-DUL
Fiyatı: 8,579.60 ₺
Özellikler
| Marka | FAG |
| Ürün No | HCB7004-C-T-P4S-DUL FAG |
| Üretici No | 0387746310000 |
| EAN | 4026677649485 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 20 |
| Dış (D) MM | 42 |
| En (B) MM | 24 |
| Ağırlık | 0.12 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 12 |
| Temel statik yük derecesi, radyal (C 0r) | 4050 |
| Limiting speed for grease lubrication (n G Grease) | 53000 |
| Limiting speed for oil lubrication (n G Oil) | 80000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
