FAG HC71919-E-T-P4S-K5-UL
Fiyatı: 22,667.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | HC71919-E-T-P4S-K5-UL FAG |
| Üretici No | 0386556910000 |
| EAN | 4026677850287 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 95 |
| Dış (D) MM | 130 |
| En (B) MM | 18 |
| İç (d) Inch | 3.7402 |
| Dış (D) Inch | 5.1181 |
| En (B) Inch | 0.7087 |
| Ağırlık | 0.578 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | K5 - P4S + K5 |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 18 |
| Temel statik yük derecesi, radyal (C 0r) | 17900 |
| Limiting speed for grease lubrication (n G Grease) | 16000 |
| Limiting speed for oil lubrication (n G Oil) | 24000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 | Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL | Single Bearing, Universal, Light Preload |
