FAG F522-WB-L

Özellikler

Marka	FAG
Ürün No	F522-WB-L FAG
Üretici No	0383830800000
EAN	4012801213219
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	270
En (B) MM	128
Ağırlık	22.2 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	100
Flange width (a) mm	270
Height flange (h 1) mm	270
Total width with cover (g 2) mm	137
Number of fastening holes	4
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft

Suffix description

W	Plummer Block Housings, Non-Split For Wide Bearings
B	Open On Both Sides
L	Flake Graphite Cast Iron (Standard)
