FAG F520-A-L

Özellikler

Marka	FAG
Ürün No	F520-A-L FAG
Üretici No	0384387800000
EAN	4012801480550
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	250
En (B) MM	119
Dış (D) Inch	9.8425
En (B) Inch	4.685
Ağırlık	18.2 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	90
Flange width (a) mm	250
Height flange (h 1) mm	250
Total width with cover (g 2) mm	119
Number of fastening holes	4
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, with conical bore and clamping sleeve, closed on one side

Suffix description

A	One End Closed
L	Grey Cast Iron
